control hatches RL
Construction:
- Made from galvanized steel or other metal
- With polymer paint coating
Installation:
- Wall or ceiling mounting
- Glue or screw fixing.
Colors: White, anthracite
EUROPLAST RL series access panels are made from galvanized steel or other metal. Depending on the model, they are coated with a polymer coating and are resistant to high humidity and mechanical damage. Designed for interior and exterior use. Inspections hatches can be mounted on the ceiling or or on the walls and fixed with glue or screws. Inspections hatches are available in a wide range of sizes.
| Article | Description | EAN | Width | Height | Depth | |
|---|---|---|---|---|---|---|
|
RL1515
|
inspection hatch metal, 150x150mm
|
4750492010044
|
150 mm | 150 mm | 30 mm |
|
RL1515A
|
inspection hatch metal, 150x150mm, anthracite
|
4750492026281
|
150 mm | 150 mm | 30 mm |
|
RL2015
|
inspection hatch metal, 200x150mm
|
4750492010211
|
150 mm | 200 mm | 30 mm |
|
RL2020
|
inspection hatch metal, 200x200mm
|
4750492100011
|
200 mm | 200 mm | 30 mm |
|
RL2020A
|
inspection hatch metal, 200x200mm, anthracite
|
4750492026298
|
200 mm | 200 mm | 30 mm |
|
RL2025
|
inspection hatch metal, 200x250mm
|
4750492010068
|
200 mm | 250 mm | 30 mm |
|
RL2030
|
inspection hatch metal, 200x300mm
|
4750492100028
|
300 mm | 200 mm | 30 mm |
|
RL3030
|
inspection hatch metal, 300x300mm
|
4750492100035
|
300 mm | 300 mm | 30 mm |
|
RL3030A
|
inspection hatch metal, 300x300mm, anthracite
|
4750492026304
|
300 mm | 300 mm | 30 mm |
|
RL3040
|
inspection hatch metal, 300x400mm
|
4750492010051
|
400 mm | 300 mm | 30 mm |
| Modifications |
| RLxxxx - white RAL9016 polymer coating |
| RLxxxxA - anthracite color polymer coating |
| *RLxxxxB - brown RAL8016 polymer coating |
| *RLxxxxY - beige RAL1015 polymer coating |
| *RLxxxxP - grey RAL9006 polymer coating |
| *RLxxxxM - black RAL9005 polymer coating |
| *RLxxxxi - stainless steel |
| * available only for orders with a certain minimum quantity |
| Type |
A (mm) |
B (mm) |
C (mm) |
D (mm) |
E (mm) |
m (kg) |
| RL1515 | 180 | 180 | 150 | 150 | 30 | 0,32 |
| RL2015 | 180 | 230 | 150 | 200 | 30 | 0,39 |
| RL2020 | 230 | 230 | 200 | 200 | 30 | 0,48 |
| RL2025 | 230 | 280 | 200 | 250 | 30 | 0,57 |
| RL2030 | 330 | 230 | 300 | 200 | 30 | 0,66 |
| RL3030 | 330 | 330 | 300 | 300 | 30 | 0,9 |
| RL3040 | 430 | 330 | 400 | 300 | 30 | 1,1 |
| RL4030 | 330 | 430 | 300 | 400 | 25 | 1,1 |
| RL4040 | 430 | 430 | 400 | 400 | 30 | 1,5 |
| RL4050 | 430 | 530 | 400 | 500 | 30 | 1,7 |
| RL5025 | 280 | 530 | 250 | 500 | 30 | 1,2 |
| RL5050 | 530 | 530 | 500 | 500 | 30 | 2,1 |
| RL6040 | 430 | 630 | 400 | 600 | 30 | 2 |
| RL6060 | 630 | 630 | 600 | 600 | 30 | 2,8 |
